N3K-C3548P-10GX - Cisco Nexus 3000 Series Switch

Cisco Nexus 3548P-10GX 10/40G Switch - Full Specifications

1. Core Features

• Model: N3K-C3548P-10GX

• Port Configuration:

  • 48 × 10G SFP+ ports (1G/10G auto-sensing)

  • 12 × 40G QSFP+ uplinks (breakout capable to 4×10G)

• Throughput: 1.44 Tbps (non-blocking)

• Forwarding Rate: 1.08 Bpps

• Latency: Ultra-low 190ns (cut-through mode)

2. Hardware Details

3. Performance & Protocols

• Buffer Memory: 12 MB shared

• MAC Address Table: 128,000 entries

• Supported Protocols:

  • L2: STP/RSTP/MSTP, VXLAN, LACP

  • L3: OSPFv2/v3, BGP, PIM, ECMP

• QoS: 8 queues per port, DSCP/CoS marking

4. Software & Management

• OS: Cisco NX-OS 7.0(3) or later

• Management:

  • CLI, SNMPv3, NetFlow

  • REST API, Python scripting

• Monitoring: sFlow, SPAN/ERSPAN

5. Certifications & Compliance

• Safety: UL/CE/CSA 60950-1

• Emissions: FCC Part 15, EN 55022 Class A

• RoHS: Compliant

• Warranty: 1-year limited hardware warranty

Packaging & Shipping Info

• Package Dimensions: 600 × 550 × 150 mm

• Gross Weight: 12 kg (with accessories)

• Included:

  • Switch chassis

  • 2× Power cords (Type depends on region)

  • Rack-mount kit

  • Quick start guide
