Cisco N3K-C3524P-10G Nexus 3500 Series Switch
N3K-C3524P-10GCisco N3K-C3524P-10G Nexus 3500 Series Switch
N3K-C3524P-10G Overview
Cisco Nexus 3548 (N3K-C3524P-10G) Technical Specifications
Key Features
Model: Nexus 3548 (N3K-C3524P-10G)
Layer: L2/L3
Port Configuration:
48 x 10G SFP+ ports (1G/10G auto-sensing)
6 x 40G QSFP+ uplinks (breakout capable to 4x10G)
Performance:
Throughput: 1.44 Tbps
Forwarding Rate: 1.2 Bpps (non-blocking)
Latency: 190ns (cut-through mode)
Hardware Details
| Parameter | Specification |
|---|---|
| Form Factor | 1RU, Rack-mountable |
| Dimensions | 17.3 x 21.6 x 1.7 in (440 x 550 x 43 mm) |
| Weight | 18.7 lb (8.5 kg) |
| Power Supply | Dual, Hot-swappable (AC/DC options) |
| Power Consumption | 150W (typical), 300W (max) |
| Cooling | Front-to-back airflow (NXA-FAN-30CFM) |
Software & Protocols
OS: Cisco NX-OS (Supports VXLAN, EVPN, BGP, OSPF)
Automation: Ansible, Puppet, Python API
QoS: 8 queues per port, DSCP/CoS marking
Advanced Technologies
Buffering: 12MB shared packet buffer
Telemetry: Advanced NetFlow, sFlow, ERSPAN
Security: MACsec-256, ACLs, DHCP Snooping
Environmental & Compliance
| Parameter | Range |
|---|---|
| Operating Temp | 32°F to 104°F (0°C to 40°C) |
| Humidity | 10% to 90% non-condensing |
| Certifications | FCC, CE, RoHS, UL |
Included Accessories
Rack-mount kit
2x Power cords (region-specific)
SFP+ SR optics (optional)
Warranty & Support
Standard Warranty: 1-year hardware replacement
Extended Options: Cisco SMART Net (24x7 support)
N3K-C3524P-10G Specification
Marketing Highlights (For Web Copy)
✔ Ultra-Low Latency: Ideal for HFT, AI/ML workloads
✔ High Density: 48x10G + 6x40G in 1RU
✔ Future-Proof: Upgradable to 25G/100G with NX-OS
N3K-C3524P-10G Warranty
 | Low Price Guarantee |  | Quality Assurance |
 | Free CCIE Expert Technical Support |  | Commodity Refund Guarantee |
 | Diversified and Flexible Transportation Services |  | Standard Policy |
