JW046A

AP type: Indoor, dual radio, 5 GHz 802.11ac 2x2 MIMO and 2.4 GHz 802.11n 2x2 MIMO

5 GHz (Radio 0)

2.4 GHz (Radio 1)

Support for up to 256 associated client devices per radio, and up to 16 BSSIDs per radio

Supported frequency bands

• 2.400 to 2.4835 GHz

• - 5.150 to 5.250 GHz

• 5.250 to 5.350 GHz

• - 5.470 to 5.725 GHz

• 5.725 to 5.850 GHz

Available channels: Dependent on configured regulatory domain

Dynamic Frequency Selection (DFS) optimizes the use of available RF spectrum

Supported radio technologies:

• 802.11b: BPSK, QPSK, CCK

• 802.11a/g/n/ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM

Transmit power: Configurable in increments of 0.5dBm

Maximum (Aggregate, conducted total) transmit power (Limited by local regulatory requirements)

• 2.4 GHz band: +21 dBm (18 dBm per chain)

• 5 GHz band: +21 dBm (18 dBm per chain)

Advanced Cellular Coexistence (ACC) minimizes the impact of interference from cellular networks

Maximum ratio combining (MRC) for improved receiver performance

Cyclic delay/shift diversity (CDD/CSD) for improved downlink RF performance
