AirEngine5761R-11E

Huawei AirEngine 5761R-11E is an outdoor AP in compliance with the Wi-Fi 6 standard (802.11ax). It stands out with excellent outdoor coverage performance, IP68 waterproof and dustproof design, and strong surge protection capability. The AP provides uplink optical and electrical ports, allowing customers to select different deployment modes and saving customers' investment. These strengths make AirEngine 5761R-11E ideal for high-density scenarios such as stadiums, squares, pedestrian streets, and amusement parks.

● The AirEngine 5761R-11E uses external antennas and supports the following radio modes:

– 2.4G+5G mode: 2.4 GHz (2x2 MIMO) and 5 GHz (2x2 MIMO).

– Dual-5G mode: 5 GHz (2x2 MIMO) and 5 GHz (2x2 MIMO).

● 1 x GE electrical port + 1 x SFP optical port

● 6 kA surge protection for Ethernet ports, IP68 waterproof and dustproof level, and extended operating temperature range of –40°C to +65°C, meeting industrial-grade requirements

● The external antenna port of the AirEngine 5761R-11E supports 5 kA surge protection, eliminating the need to install an external surge protector, simplifying installation, and reducing the overall cost.

● Bluetooth serial interface-based O&M through the built-in Bluetooth module by collaborating with CloudCampus APP; collaboration with a location server to accurately locate Bluetooth terminals and tags

● Working modes: Fit, Fat, and cloud management
